Feature:
Universal AC input, 110V/220V is selectable by switch
Protection types: Short circuit / Overload / Over voltage
Auto-recovery after protection
Forced air cooling by built-in DC fan
PWM control and regulation
100% full load burn-in test
Design with Built-in EMI Filter
LED indication for power on
Lower Power consumption, Lower Temperature, High efficiency, High reliability
Specification:
Model: 0010132
Size: 220 x 115 x 60 mm (8.7 x 4.5 x 2.4 inches)
Input: 100~120VAC or 200~240VAC
Frequency range: 50/60Hz
Output: DC 12V
Voltage adjustment range: ±10%
Rated current: 50A
Rated power: 600W
Overload: 110~150% rated output power
Over voltage: 13.8~16.2V
Working temperature: -20°C ~ +70°C
